Thermal Grease
Thermal Grease
Features:
This product is made of metal oxides and polyorganosiloxanes with good thermal conductivity and insulation properties.- Thermal conductivity 1.5W/(m.K)
- Excellent electrical insulation
- Wide operating temperature: Operating temperature -50~200°C
- Do not dry at high temperatures, no oil
- Non-toxic, odorless, non-corrosive and environmentally friendly.
Purchase
Add to inquiry box
Exchange
Features:
This product is made of metal oxides and polyorganosiloxanes with good thermal conductivity and insulation properties.- Thermal conductivity 1.5W/(m.K)
- Excellent electrical insulation
- Wide operating temperature: Operating temperature -50~200°C
- Do not dry at high temperatures, no oil
- Non-toxic, odorless, non-corrosive and environmentally friendly.
Production information
Applications
- Widely used as a heat transfer medium for electronic components, such as CPU and heat sinks, high-power triodes, controllable germanium diodes and substrate (aluminum, copper) contact gap filling, reducing the operating temperature of the heating element, High viscosity type, especially suitable for manual dispensing.
Using process
- Clean the surface to be coated to remove oil stains
- For smoother dispensing, it is recommended to use the iron bar to fully stir 2min2min2min2min before dispensing the machine.
- Then the thermal grease can be directly extruded on the surface to be coated.
- Note that the construction surface should be uniform, as long as it is coated with a thin layer.
Packing specification
- 1KG/barrel
Storage and transportation
- The storage period of this product is 1 year (25°C).
- Such products are non-dangerous and can be transported as general chemicals.
Precautions
- The use of thermal grease is not as good as possible, but it should be as thin as possible while ensuring that the gap is filled.
